Qwik Box
Qwik Box is a software-based solution running on commodity hardware. By virtualizing network functions such as routing, firewalling, and VPN, SVB offers flexibility, scalability, and cost-efficiency...
- Virtualizes network functions on commodity hardware
- Provides flexibility, scalability, and cost-efficiency
- QT 1-2-3: complete ICTaaS solution
- Diverse connectivity and zero-touch deployment
- Costs under $50 per site per month
- Self-managed, co-managed, fully managed with 24/7 support
- A framework to deploy – ISP in a Box, ICTaaS, Secure SD-WAN
- Open source, hosted, managed
- Automation & Scale Speed, flexibility, zero-touch, policy-driven
- Security, role-based access, threat mitigation
- Assurance & Analytics, Monitoring and Reporting
QT 1-2-3 is a complete ICTaaS solution...
Benefits
- Disaggregation & Lowered costs
- Simplification & Scale
- Real-time Visibility
- Flexibility & Control
- Agility & Automation
- Easier to Manage
Qwik Box-Software
- Software-based solution supporting multiple applications
- Type 1 Hypervisor
- Hardware Abstraction for underlying resources
- Application Management:
- Create
- Delete
- Start/Stop
- Pause/Resume
- Management Interface for administrators
- Web-based console and API for automation
- Supports Linux, Windows, BSD, etc.
Product Parameters:
| Configurations/Parameter | Four network soft routing form |
|---|---|
 |
Intel 12th Gen Alder Lake-N N100/N200/13-N305 |
 |
On board 8G/16G LPDDR5 4800MHz optional |
 |
1 * M.2 2242 SATA/NGFF/NVMe (PCIe3.0 x2) protocol |
 |
Intel UHD Graphics N100(24EU) / N200(32EU)/13-N305(32EU) |
 |
1 * HDMI2.0 (4096 x 2160@60Hz), 1 Type-C (4096 x 2160@60Hz) |
 |
4 * Intel i226-V(2.5G Network card) |
 |
2 * USB3.1 Gen2 10Gbps(USB-A). 1 USB3.1 Gen2 10Gbps(USB-C) |
 |
NONE |
 |
Realtek ACL897 pitch 2.1 2-in-1 audio interface |
 |
Dual copper tube fin heat dissipation PMW four wire temperature controlled silent ball fan |
 |
75.4mm 75.4mm 52.5mm |
 |
AMI EFI BIOS supports auto power-on, wake on lan, and PXE |
 |
DC-IN 12-19V wide voltage (Type-C interface) PD 55W or above charger 100-240VAC, 50/60Hz |
 |
-10-75 °C 10%-90% relative humidity |
 |
Windows11、Ubuntu、Linux etc OS |
Qwik Box-Hardware
- Technical Specifications Summary:
- CPU: Intel 4, 8, or 16 core
- Networking Ports: 6 x 1G copper, 2 x 10G SFP+
- USB Ports: 2x USB 3.0 type A
- Storage: M.2 SATA SSD (120GB or 240GB)
- Memory: DDR4/DDR5 with ECC support
- Operating System: YCN Hypervisor
- Mounting: Wall, rack, or desktop
